K88R58減速機詳細信息
K88R58減速機
K88R58減速機電機功率：K88R58Y0.12KW減速機,K88R58Y0.18KW減速機,K88R58Y0.25KW減速機,K88R58Y0.37KW減速機,K88R58Y0.55KW減速機,K88R58Y0.75KW減速機,K88R58Y1.1KW減速機,K88R58Y1.5KW減速機（可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機）。
K88R58減速機配0.12KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| K88R58-Y0.12KW | 5240 | 0.12KW | 0.26r/min | 3470N.m | 108.5kg | 26200N | 0.80 |
| K88R58-Y0.12KW | 4562 | 0.12KW | 0.30r/min | 2890N.m | 108.5kg | 27000N | 0.95 |
| K88R58-Y0.12KW | 4037 | 0.12KW | 0.34r/min | 2680N.m | 108.5kg | 27300N | 1.00 |
| K88R58-Y0.12KW | 3609 | 0.12KW | 0.38r/min | 2390N.m | 108.5kg | 27600N | 1.15 |
| K88R58-Y0.12KW | 3107 | 0.12KW | 0.44r/min | 2060N.m | 108.5kg | 28000N | 1.30 |
| K88R58-Y0.12KW | 2728 | 0.12KW | 0.51r/min | 1730N.m | 108.5kg | 28300N | 1.55 |
| K88R58-Y0.12KW | 2371 | 0.12KW | 0.58r/min | 1530N.m | 108.5kg | 28400N | 1.75 |
| K88R58-Y0.12KW | 2088 | 0.12KW | 0.66r/min | 1430N.m | 108.5kg | 28500N | 1.90 |
| K88R58-Y0.12KW | 1854 | 0.12KW | 0.74r/min | 1270N.m | 108.5kg | 28600N | 2.10 |
| K88R58-Y0.12KW | 1657 | 0.12KW | 0.83r/min | 1130N.m | 108.5kg | 28700N | 2.40 |
| K88R58-Y0.12KW | 1415 | 0.12KW | 0.97r/min | 960N.m | 108.5kg | 28800N | 2.80 |
| K88R58-Y0.12KW | 1229 | 0.12KW | 1.10r/min | 830N.m | 108.5kg | 28900N | 3.20 |
| K88R58-Y0.12KW | 1078 | 0.12KW | 1.30r/min | 720N.m | 108.5kg | 28900N | 3.70 |
| K88R58-Y0.12KW | 951 | 0.12KW | 1.40r/min | 610N.m | 108.5kg | 29000N | 4.40 |
| K88R58-Y0.12KW | 837 | 0.12KW | 1.60r/min | 520N.m | 108.5kg | 29000N | 5.20 |
| K88R58-Y0.12KW | 726 | 0.12KW | 1.90r/min | 450N.m | 108.5kg | 29000N | 5.90 |
K88R58減速機配0.18KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| K88R58-Y0.18KW | 3107 | 0.18KW | 0.42r/min | 3430N.m | 109kg | 26200N | 0.80 |
| K88R58-Y0.18KW | 2728 | 0.18KW | 0.48r/min | 2920N.m | 109kg | 27000N | 0.90 |
| K88R58-Y0.18KW | 2371 | 0.18KW | 0.56r/min | 2560N.m | 109kg | 27400N | 1.05 |
| K88R58-Y0.18KW | 2088 | 0.18KW | 0.63r/min | 2350N.m | 109kg | 27700N | 1.15 |
| K88R58-Y0.18KW | 1854 | 0.18KW | 0.71r/min | 2080N.m | 109kg | 28000N | 1.30 |
| K88R58-Y0.18KW | 1657 | 0.18KW | 0.80r/min | 1860N.m | 109kg | 28200N | 1.45 |
| K88R58-Y0.18KW | 1415 | 0.18KW | 0.93r/min | 1590N.m | 109kg | 28400N | 1.70 |
| K88R58-Y0.18KW | 1229 | 0.18KW | 1.10r/min | 1380N.m | 109kg | 28600N | 1.95 |
| K88R58-Y0.18KW | 1078 | 0.18KW | 1.20r/min | 1200N.m | 109kg | 28700N | 2.20 |
| K88R58-Y0.18KW | 951 | 0.18KW | 1.40r/min | 1030N.m | 109kg | 28800N | 2.60 |
| K88R58-Y0.18KW | 837 | 0.18KW | 1.60r/min | 890N.m | 109kg | 28800N | 3.00 |
| K88R58-Y0.18KW | 726 | 0.18KW | 1.80r/min | 775N.m | 109kg | 28900N | 3.50 |
K88R58減速機配0.25KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| K88R58-Y0.25KW | 2088 | 0.25KW | 0.62r/min | 3390N.m | 113kg | 26300N | 0.80 |
| K88R58-Y0.25KW | 1854 | 0.25KW | 0.70r/min | 3010N.m | 113kg | 26900N | 0.90 |
| K88R58-Y0.25KW | 1657 | 0.25KW | 0.78r/min | 2690N.m | 113kg | 27300N | 1.00 |
| K88R58-Y0.25KW | 1415 | 0.25KW | 0.92r/min | 2290N.m | 113kg | 27800N | 1.15 |
| K88R58-Y0.25KW | 1229 | 0.25KW | 1.10r/min | 1990N.m | 113kg | 28100N | 1.35 |
| K88R58-Y0.25KW | 1078 | 0.25KW | 1.20r/min | 1730N.m | 113kg | 28300N | 1.55 |
| K88R58-Y0.25KW | 951 | 0.25KW | 1.40r/min | 1500N.m | 113kg | 28500N | 1.80 |
| K88R58-Y0.25KW | 837 | 0.25KW | 1.60r/min | 1310N.m | 113kg | 28600N | 2.10 |
| K88R58-Y0.25KW | 726 | 0.25KW | 1.80r/min | 1130N.m | 113kg | 28700N | 2.40 |
| K88R58-Y0.25KW | 638 | 2.00r/min | 1010N.m | 113kg | 28800N | 2.70 |
K88R58減速機配0.37KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| K88R58-Y0.37KW | 1415 | 0.37KW | 0.97r/min | 3250N.m | 113.5kg | 26500N | 0.85 |
| K88R58-Y0.37KW | 1229 | 0.37KW | 1.10r/min | 2820N.m | 113.5kg | 27100N | 0.95 |
| K88R58-Y0.37KW | 1078 | 0.37KW | 1.30r/min | 2460N.m | 113.5kg | 27600N | 1.10 |
| K88R58-Y0.37KW | 951 | 0.37KW | 1.40r/min | 2140N.m | 113.5kg | 27900N | 1.25 |
| K88R58-Y0.37KW | 837 | 0.37KW | 1.60r/min | 1870N.m | 113.5kg | 28200N | 1.45 |
| K88R58-Y0.37KW | 726 | 0.37KW | 1.90r/min | 1620N.m | 113.5kg | 28400N | 1.65 |
| K88R58-Y0.37KW | 638 | 0.37KW | 2.20r/min | 1440N.m | 113.5kg | 28500N | 1.85 |
| K88R58-Y0.37KW | 562 | 0.37KW | 2.50r/min | 1250N.m | 113.5kg | 28600N | 2.20 |
| K88R58-Y0.37KW | 474 | 0.37KW | 2.90r/min | 1050N.m | 113.5kg | 28800N | 2.60 |
| K88R58-Y0.37KW | 426 | 0.37KW | 3.20r/min | 950N.m | 113.5kg | 28800N | 2.80 |
| K88R58-Y0.37KW | 373 | 0.37KW | 3.70r/min | 830N.m | 113.5kg | 28900N | 3.20 |
K88R58減速機配0.55KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| K88R58-Y0.55KW | 951 | 0.55KW | 1.40r/min | 3250N.m | 118kg | 26500N | 0.85 |
| K88R58-Y0.55KW | 837 | 0.55KW | 1.60r/min | 2840N.m | 118kg | 27100N | 0.95 |
| K88R58-Y0.55KW | 726 | 0.55KW | 1.90r/min | 2470N.m | 118kg | 27600N | 1.10 |
| K88R58-Y0.55KW | 638 | 0.55KW | 2.20r/min | 2180N.m | 118kg | 27900N | 1.25 |
| K88R58-Y0.55KW | 562 | 0.55KW | 2.50r/min | 1910N.m | 118kg | 28100N | 1.40 |
| K88R58-Y0.55KW | 474 | 0.55KW | 2.90r/min | 1610N.m | 118kg | 28400N | 1.70 |
| K88R58-Y0.55KW | 426 | 0.55KW | 3.20r/min | 1440 N.m | 118kg | 28500N | 1.85 |
| K88R58-Y0.55KW | 373 | 0.55KW | 3.70r/min | 1270N.m | 118kg | 28600N | 2.10 |
| K88R58-Y0.55KW | 330 | 0.55KW | 4.20r/min | 1100N.m | 118kg | 28700N | 2.40 |
| K88R58-Y0.55KW | 294 | 0.55KW | 4.70r/min | 990N.m | 118kg | 28800N | 2.70 |
| K88R58-Y0.55KW | 250 | 0.55KW | 5.50r/min | 860N.m | 118kg | 28900N | 3.10 |
| K88R58-Y0.55KW | 236 | 0.55KW | 5.80r/min | 810N.m | 118kg | 28900N | 3.30 |
| K88R58-Y0.55KW | 201 | 0.55KW | 6.90r/min | 685N.m | 118kg | 28900N | 3.90 |
K88R58減速機配0.75KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| K88R58-Y0.75KW | 726 | 0.75KW | 2.00r/min | 3270N.m | 119kg | 26500N | 0.80 |
| K88R58-Y0.75KW | 638 | 0.75KW | 2.20r/min | 2890N.m | 119kg | 27000N | 0.95 |
| K88R58-Y0.75KW | 562 | 0.75KW | 2.60r/min | 2530N.m | 119kg | 27500N | 1.05 |
| K88R58-Y0.75KW | 474 | 0.75KW | 3.00r/min | 2130N.m | 119kg | 27900N | 1.25 |
| K88R58-Y0.75KW | 426 | 0.75KW | 3.40r/min | 1910N.m | 119kg | 28100N | 1.40 |
| K88R58-Y0.75KW | 373 | 0.75KW | 3.80r/min | 1680N.m | 119kg | 28300N | 1.60 |
| K88R58-Y0.75KW | 330 | 0.75KW | 4.40r/min | 1470N.m | 119kg | 28500N | 1.85 |
| K88R58-Y0.75KW | 294 | 0.75KW | 4.90r/min | 1310N.m | 119kg | 28600N | 2.0 |
| K88R58-Y0.75KW | 250 | 0.75KW | 5.70r/min | 1130N.m | 119kg | 28700N | 2.4 |
| K88R58-Y0.75KW | 236 | 0.75KW | 6.10r/min | 1070N.m | 119kg | 28700N | 2.5 |
| K88R58-Y0.75KW | 201 | 0.75KW | 7.10r/min | 910N.m | 119kg | 28800N | 3.0 |
K88R58減速機配1.1KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| K88R58-Y1.1KW | 474 | 1.1KW | 3.00r/min | 3200N.m | 123kg | 26600N | 0.85 |
| K88R58-Y1.1KW | 426 | 1.1KW | 3.30r/min | 2870N.m | 123kg | 27100N | 0.95 |
| K88R58-Y1.1KW | 373 | 1.1KW | 3.80r/min | 2530N.m | 123kg | 27500N | 1.05 |
| K88R58-Y1.1KW | 330 | 1.1KW | 4.30r/min | 2210N.m | 123kg | 27800N | 1.20 |
| K88R58-Y1.1KW | 294 | 1.1KW | 4.80r/min | 1980N.m | 123kg | 28100N | 1.35 |
| K88R58-Y1.1KW | 250 | 1.1KW | 5.70r/min | 1700N.m | 123kg | 28300N | 1.60 |
| K88R58-Y1.1KW | 236 | 1.1KW | 6.00r/min | 1610N.m | 123kg | 28400N | 1.70 |
| K88R58-Y1.1KW | 201 | 1.1KW | 7.10r/min | 1360N.m | 123kg | 28600N | 1.95 |
K88R58減速機配1.5KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| K88R58-Y1.5KW | 330 | 1.5KW | 4.30r/min | 3020N.m | 126kg | 26900N | 0.90 |
| K88R58-Y1.5KW | 294 | 1.5KW | 4.90r/min | 2700N.m | 126kg | 27300N | 1.00 |
| K88R58-Y1.5KW | 250 | 1.5KW | 5.70r/min | 2320N.m | 126kg | 27700N | 1.15 |
| K88R58-Y1.5KW | 236 | 1.5KW | 6.00r/min | 2190N.m | 126kg | 27900N | 1.25 |
| K88R58-Y1.5KW | 201 | 1.5KW | 7.10r/min | 1860N.m | 126kg | 28200N | 1.45 |
| K88R58-Y1.5KW | 183 | 1.5KW | 7.80r/min | 1690N.m | 126kg | 28300N | 1.60 |
K88R58減速器減速比：183比減速器,201比減速器,236比減速器,250比齒輪減速馬達,294比減速器,330比減速器,373比減速器,426比減速器,474比減速器,562比減速器,638比減速器,726比減速器,837比減速器,951比減速器,1078比減速器,1229比減速器,1415比減速器,1657比減速器,1854比減速器,2088比減速器,2371比減速器,2728比減速器,3107比減速器,3609比減速器,4037比減速器,4562比減速器,5240比減速器。
K88R58減速機電機安裝尺寸：輸出軸+鍵Φ64（可定做），高340*寬354（帶輸出軸）*長576
K88R58減速電機輸出轉數：0.26轉減速電機,0.3轉減速電機,0.34轉減速電機,0.38轉減速電機,0.42轉減速電機,0.44轉減速電機,0.48轉減速電機,0.51轉減速電機,0.56轉減速電機,0.58轉減速電機,0.62轉減速電機,0.63轉減速電機,0.66轉減速電機,0.7轉減速電機,0.71轉減速電機,0.74轉減速電機,0.78轉減速電機,0.8轉減速電機,0.83轉減速電機,0.92轉減速電機,0.93轉減速電機,0.97轉減速電機,1.1轉減速電機,1.2轉減速電機,1.3轉減速電機,1.4轉減速電機,1.6轉減速電機,1.8轉減速電機,1.9轉減速電機,2轉減速電機,2.2轉減速電機,2.5轉減速電機,2.6轉減速電機,2.9轉減速電機,3轉直角減速機,3.2轉減速電機,3.3轉減速電機,3.4轉減速電機,3.7轉減速電機,3.8轉減速電機,4.2轉減速電機,4.3轉減速電機,4.4轉減速電機,4.7轉減速電機,4.8轉減速電機,4.9轉減速電機,5.5轉減速電機,5.7轉減速電機,5.8轉減速電機,6轉減速電機,6.1轉減速電機,6.9轉減速電機,7.1轉減速電機,7.8轉減速電機。
K88R58減速箱電機輸出扭矩：450N.m減速箱,520N.m減速箱,610N.m減速箱,685N.m減速箱,720N.m減速箱,775N.m減速箱,810N.m減速箱,830N.m減速箱,860N.m減速箱,890N.m減速箱,910N.m減速箱,950N.m減速箱,960N.m減速箱,990N.m減速箱,1010N.m減速箱,1030N.m減速箱,1050N.m減速箱,1070N.m減速箱,1100N.m減速箱,1130N.m減速箱,1200N.m減速箱,1250N.m減速箱,1270N.m減速箱,1310N.m減速箱,1360N.m減速箱,1380N.m減速箱,1430N.m減速箱,1440N.m減速箱,1470N.m減速箱,1500N.m減速箱,1530N.m減速箱,1590N.m減速箱,1610N.m減速箱,1620N.m減速箱,1680N.m減速箱,1690N.m減速箱,1700N.m減速箱,1730N.m減速箱,1860N.m減速箱,1870N.m減速箱,1910N.m減速箱,1980N.m減速箱,1990N.m減速箱,2060N.m減速箱,2080N.m減速箱,2130N.m減速箱,2140N.m減速箱,2180N.m減速箱,2190N.m減速箱,2210N.m減速箱,2290N.m減速箱,2320N.m減速箱,2350N.m減速箱,2390N.m減速箱,2460N.m減速箱,2470N.m減速箱,2530N.m減速箱,2560N.m減速箱,2680N.m減速箱,2690N.m減速箱,2700N.m減速箱,2820N.m減速箱,2840N.m減速箱,2870N.m減速箱,2890N.m減速箱,2920N.m減速箱,3010N.m減速箱,3020N.m減速箱,3200N.m減速箱,3250N.m減速箱,3270N.m減速箱,3390N.m減速箱,3430N.m減速箱,3470N.m減速箱。
K88R58減速機電機各種輸出實物圖：
K88R58減速馬達型號：
KHZ87RF57-Y0.12KW,KHZ87R57DM63L4,KHZ87R57DM63M4,KHZ87R57DM63MS4,KHZ87R57DM63S4,KHZ87R57DM71D4,KHZ87R57DM71M4,KHZ87R57DM71MS4,KHZ87R57DM71S4,KHZ87R57DM80K4,KHZ87R57DM80M4,KHZ87R57DM80MK4,KHZ87R57DM80N4,KHZ87R57DM80S4,KHZ87R57DM90L4,KHZ87R57DM90M4,KHZ87R57DM90S4,KHZ87R57DR63L4,KHZ87R57DR63M4,KHZ87R57DR63MS4,KHZ87R57DR63S4,KHZ87R57DR71D4,KHZ87R57DR71M4,KHZ87R57DR71MS4,KHZ87R57DR71S4,KHZ87R57DR80K4,KHZ87R57DR80M4,KHZ87R57DR80MK4,KHZ87R57DR80N4,KHZ87R57DR80S4,KHZ87R57DR90L4,KHZ87R57DR90M4,KHZ87R57DR90S4,KHZ87R57DRE63L4,KHZ87R57DRE63M4,KHZ87R57DRE63MS4,KHZ87R57DRE63S4,KHZ87R57DRE71D4,KHZ87R57DRE71M4,KHZ87R57DRE71MS4,KHZ87R57DRE71S4,KHZ87R57DRE80K4,KHZ87R57DRE80M4,KHZ87R57DRE80MK4,KHZ87R57DRE80N4,KHZ87R57DRE80S4,KHZ87R57DRE90L4,KHZ87R57DRE90M4,KHZ87R57DRE90S4,KHZ87R57DRN63L4,KHZ87R57DRN63M4,KHZ87R57DRN63MS4,KHZ87R57DRN63S4,KHZ87R57DRN71D4,KHZ87R57DRN71M4,KHZ87R57DRN71MS4,KHZ87R57DRN71S4,KHZ87R57DRN80K4,KHZ87R57DRN80M4,KHZ87R57DRN80MK4,KHZ87R57DRN80N4,KHZ87R57DRN80S4,KHZ87R57DRN90L4,KHZ87R57DRN90M4,KHZ87R57DRN90S4,KHZ87R57DRS63L4,KHZ87R57DRS63M4,KHZ87R57DRS63MS4,KHZ87R57DRS63S4,KHZ87R57DRS71D4,KHZ87R57DRS71M4,KHZ87R57DRS71MS4,KHZ87R57DRS71S4,KHZ87R57DRS80K4,KHZ87R57DRS80M4,KHZ87R57DRS80MK4,KHZ87R57DRS80N4,KHZ87R57DRS80S4,KHZ87R57DRS90L4,KHZ87R57DRS90M4,KHZ87R57DRS90S4,KHZ87R57DT63L4,KHZ87R57DT63M4,KHZ87R57DT63MS4,KHZ87R57DT63S4,KHZ87R57DT71D4,KHZ87R57DT71M4,KHZ87R57DT71MS4,KHZ87R57DT71S4,KHZ87R57DT80K4,KHZ87R57DT80M4,KHZ87R57DT80MK4,KHZ87R57DT80N4,KHZ87R57DT80S4,KHZ87R57DT90L4,KHZ87R57DT90M4,KHZ87R57DT90S4,KHZ87R57DV63L4,KHZ87R57DV63M4,KHZ87R57DV63MS4,KHZ87R57DV63S4,KHZ87R57DV71D4,KHZ87R57DV71M4,KHZ87R57DV71MS4,KHZ87R57DV71S4,KHZ87R57DV80K4,KHZ87R57DV80M4,KHZ87R57DV80MK4,KHZ87R57DV80N4,KHZ87R57DV80S4,KHZ87R57DV90L4,KHZ87R57DV90M4,KHZ87R57DV90S4,KHZ87R57DVE63L4,KHZ87R57DVE63M4,KHZ87R57DVE63MS4,KHZ87R57DVE63S4,KHZ87R57DVE71D4,KHZ87R57DVE71M4,KHZ87R57DVE71MS4,KHZ87R57DVE71S4,KHZ87R57DVE80K4,KHZ87R57DVE80M4,KHZ87R57DVE80MK4,KHZ87R57DVE80N4,KHZ87R57DVE80S4,KHZ87R57DVE90L4,KHZ87R57DVE90M4,KHZ87R57DVE90S4,KHZ87RF57-Y0.12KW,KHZ87RF57-Y0.12KW,KHZ87RF57-Y0.12KW,KHZ87RF57-Y0.18KW,KHZ87RF57-Y0.18KW,KHZ87RF57-Y0.18KW,KHZ87RF57-Y0.18KW,KHZ87RF57-Y0.25KW,KHZ87RF57-Y0.25KW,KHZ87RF57-Y0.25KW,KHZ87RF57-Y0.25KW,KHZ87RF57-Y0.37KW,KHZ87RF57-Y0.37KW,KHZ87RF57-Y0.37KW,KHZ87RF57-Y0.37KW,KHZ87RF57-Y0.55KW,KHZ87RF57-Y0.55KW,KHZ87RF57-Y0.55KW,KHZ87RF57-Y0.55KW,KHZ87RF57-Y0.75KW,KHZ87RF57-Y0.75KW,KHZ87RF57-Y0.75KW,KHZ87RF57-Y0.75KW,KHZ87RF57-Y1.1KW,KHZ87RF57-Y1.1KW,KHZ87RF57-Y1.1KW,KHZ87RF57-Y1.1KW,KHZ87RF57-Y1.5KW,KHZ87RF57-Y1.5KW,KHZ87RF57-Y1.5KW,KHZ87RF57-Y1.5KW,KHZ87RF57-Y63M4,KHZ87RF57-Y71M4,KHZ87RF57-Y80M4,KHZ87RF57-Y90M4,KHZ87RF57-YEJ63M4,KHZ87RF57-YEJ71M4,KHZ87RF57-YEJ80M4,KHZ87RF57-YEJ90S4,KHZ87RF57-YVP63M4,KHZ87RF57-YVP71M4,KHZ87RF57-YVP80M4,KHZ87RF57-YVP90S4,KHZ87RF57-YVPEJ63M4,KHZ87RF57-YVPEJ71M4,KHZ87RF57-YVPEJ80M4,KHZ87RF57-YVPEJ90S4,KVZ87RF57-Y0.12KW,KVZ87R57DM63L4,KVZ87R57DM63M4,KVZ87R57DM63MS4,KVZ87R57DM63S4,KVZ87R57DM71D4,KVZ87R57DM71M4,KVZ87R57DM71MS4,KVZ87R57DM71S4,KVZ87R57DM80K4,KVZ87R57DM80M4,KVZ87R57DM80MK4,KVZ87R57DM80N4,KVZ87R57DM80S4,KVZ87R57DM90L4,KVZ87R57DM90M4,KVZ87R57DM90S4,KVZ87R57DR63L4,KVZ87R57DR63M4,KVZ87R57DR63MS4,KVZ87R57DR63S4,KVZ87R57DR71D4,KVZ87R57DR71M4,KVZ87R57DR71MS4,KVZ87R57DR71S4,KVZ87R57DR80K4,KVZ87R57DR80M4,KVZ87R57DR80MK4,KVZ87R57DR80N4,KVZ87R57DR80S4,KVZ87R57DR90L4,KVZ87R57DR90M4,KVZ87R57DR90S4,KVZ87R57DRE63L4,KVZ87R57DRE63M4,KVZ87R57DRE63MS4,KVZ87R57DRE63S4,KVZ87R57DRE71D4,KVZ87R57DRE71M4,KVZ87R57DRE71MS4,KVZ87R57DRE71S4,KVZ87R57DRE80K4,KVZ87R57DRE80M4,KVZ87R57DRE80MK4,KVZ87R57DRE80N4,KVZ87R57DRE80S4,KVZ87R57DRE90L4,KVZ87R57DRE90M4,KVZ87R57DRE90S4,KVZ87R57DRN63L4,KVZ87R57DRN63M4,KVZ87R57DRN63MS4,KVZ87R57DRN63S4,KVZ87R57DRN71D4,KVZ87R57DRN71M4,KVZ87R57DRN71MS4,KVZ87R57DRN71S4,KVZ87R57DRN80K4,KVZ87R57DRN80M4,KVZ87R57DRN80MK4,KVZ87R57DRN80N4,KVZ87R57DRN80S4,KVZ87R57DRN90L4,KVZ87R57DRN90M4,KVZ87R57DRN90S4,KVZ87R57DRS63L4,KVZ87R57DRS63M4,KVZ87R57DRS63MS4,KVZ87R57DRS63S4,KVZ87R57DRS71D4,KVZ87R57DRS71M4,KVZ87R57DRS71MS4,KVZ87R57DRS71S4,KVZ87R57DRS80K4,KVZ87R57DRS80M4,KVZ87R57DRS80MK4,KVZ87R57DRS80N4,KVZ87R57DRS80S4,KVZ87R57DRS90L4,KVZ87R57DRS90M4,KVZ87R57DRS90S4,KVZ87R57DT63L4,KVZ87R57DT63M4,KVZ87R57DT63MS4,KVZ87R57DT63S4,KVZ87R57DT71D4,KVZ87R57DT71M4,KVZ87R57DT71MS4,KVZ87R57DT71S4,KVZ87R57DT80K4,KVZ87R57DT80M4,KVZ87R57DT80MK4,KVZ87R57DT80N4,KVZ87R57DT80S4,KVZ87R57DT90L4,KVZ87R57DT90M4,KVZ87R57DT90S4,KVZ87R57DV63L4,KVZ87R57DV63M4,KVZ87R57DV63MS4,KVZ87R57DV63S4,KVZ87R57DV71D4,KVZ87R57DV71M4,KVZ87R57DV71MS4,KVZ87R57DV71S4,KVZ87R57DV80K4,KVZ87R57DV80M4,KVZ87R57DV80MK4,KVZ87R57DV80N4,KVZ87R57DV80S4,KVZ87R57DV90L4,KVZ87R57DV90M4,KVZ87R57DV90S4,KVZ87R57DVE63L4,KVZ87R57DVE63M4,KVZ87R57DVE63MS4,KVZ87R57DVE63S4,KVZ87R57DVE71D4,KVZ87R57DVE71M4,KVZ87R57DVE71MS4,KVZ87R57DVE71S4,KVZ87R57DVE80K4,KVZ87R57DVE80M4,KVZ87R57DVE80MK4,KVZ87R57DVE80N4,KVZ87R57DVE80S4,KVZ87R57DVE90L4,KVZ87R57DVE90M4,KVZ87R57DVE90S4,KVZ87RF57-Y0.12KW,KVZ87RF57-Y0.12KW,KVZ87RF57-Y0.12KW,KVZ87RF57-Y0.18KW,KVZ87RF57-Y0.18KW,KVZ87RF57-Y0.18KW,KVZ87RF57-Y0.18KW,KVZ87RF57-Y0.25KW,KVZ87RF57-Y0.25KW,KVZ87RF57-Y0.25KW,KVZ87RF57-Y0.25KW,KVZ87RF57-Y0.37KW,KVZ87RF57-Y0.37KW,KVZ87RF57-Y0.37KW,KVZ87RF57-Y0.37KW,KVZ87RF57-Y0.55KW,KVZ87RF57-Y0.55KW,KVZ87RF57-Y0.55KW,KVZ87RF57-Y0.55KW,KVZ87RF57-Y0.75KW,KVZ87RF57-Y0.75KW,KVZ87RF57-Y0.75KW,KVZ87RF57-Y0.75KW,KVZ87RF57-Y1.1KW,KVZ87RF57-Y1.1KW,KVZ87RF57-Y1.1KW,KVZ87RF57-Y1.1KW,KVZ87RF57-Y1.5KW,KVZ87RF57-Y1.5KW,KVZ87RF57-Y1.5KW,KVZ87RF57-Y1.5KW,KVZ87RF57-Y63M4,KVZ87RF57-Y71M4,KVZ87RF57-Y80M4,KVZ87RF57-Y90M4,KVZ87RF57-YEJ63M4,KVZ87RF57-YEJ71M4,KVZ87RF57-YEJ80M4,KVZ87RF57-YEJ90S4,KVZ87RF57-YVP63M4,KVZ87RF57-YVP71M4,KVZ87RF57-YVP80M4,KVZ87RF57-YVP90S4,KVZ87RF57-YVPEJ63M4,KVZ87RF57-YVPEJ71M4,KVZ87RF57-YVPEJ80M4,KVZ87RF57-YVPEJ90S4,KAZ87RF57-Y0.12KW,KAZ87R57DM63L4,KAZ87R57DM63M4,KAZ87R57DM63MS4,KAZ87R57DM63S4,KAZ87R57DM71D4,KAZ87R57DM71M4,KAZ87R57DM71MS4,KAZ87R57DM71S4,KAZ87R57DM80K4,KAZ87R57DM80M4,KAZ87R57DM80MK4,KAZ87R57DM80N4,KAZ87R57DM80S4,KAZ87R57DM90L4,KAZ87R57DM90M4,KAZ87R57DM90S4,KAZ87R57DR63L4,KAZ87R57DR63M4,KAZ87R57DR63MS4,KAZ87R57DR63S4,KAZ87R57DR71D4,KAZ87R57DR71M4,KAZ87R57DR71MS4,KAZ87R57DR71S4,KAZ87R57DR80K4,KAZ87R57DR80M4,KAZ87R57DR80MK4,KAZ87R57DR80N4,KAZ87R57DR80S4,KAZ87R57DR90L4,KAZ87R57DR90M4,KAZ87R57DR90S4,KAZ87R57DRE63L4,KAZ87R57DRE63M4,KAZ87R57DRE63MS4,KAZ87R57DRE63S4,KAZ87R57DRE71D4,KAZ87R57DRE71M4,KAZ87R57DRE71MS4,KAZ87R57DRE71S4,KAZ87R57DRE80K4,KAZ87R57DRE80M4,KAZ87R57DRE80MK4,KAZ87R57DRE80N4,KAZ87R57DRE80S4,KAZ87R57DRE90L4,KAZ87R57DRE90M4,KAZ87R57DRE90S4,KAZ87R57DRN63L4,KAZ87R57DRN63M4,KAZ87R57DRN63MS4,KAZ87R57DRN63S4,KAZ87R57DRN71D4,KAZ87R57DRN71M4,KAZ87R57DRN71MS4,KAZ87R57DRN71S4,KAZ87R57DRN80K4,KAZ87R57DRN80M4,KAZ87R57DRN80MK4,KAZ87R57DRN80N4,KAZ87R57DRN80S4,KAZ87R57DRN90L4,KAZ87R57DRN90M4,KAZ87R57DRN90S4,KAZ87R57DRS63L4,KAZ87R57DRS63M4,KAZ87R57DRS63MS4,KAZ87R57DRS63S4,KAZ87R57DRS71D4,KAZ87R57DRS71M4,KAZ87R57DRS71MS4,KAZ87R57DRS71S4,KAZ87R57DRS80K4,KAZ87R57DRS80M4,KAZ87R57DRS80MK4,KAZ87R57DRS80N4,KAZ87R57DRS80S4,KAZ87R57DRS90L4,KAZ87R57DRS90M4,KAZ87R57DRS90S4,KAZ87R57DT63L4,KAZ87R57DT63M4,KAZ87R57DT63MS4,KAZ87R57DT63S4,KAZ87R57DT71D4,KAZ87R57DT71M4,KAZ87R57DT71MS4,KAZ87R57DT71S4,KAZ87R57DT80K4,KAZ87R57DT80M4,KAZ87R57DT80MK4,KAZ87R57DT80N4,KAZ87R57DT80S4,KAZ87R57DT90L4,KAZ87R57DT90M4,KAZ87R57DT90S4,KAZ87R57DV63L4,KAZ87R57DV63M4,KAZ87R57DV63MS4,KAZ87R57DV63S4,KAZ87R57DV71D4,KAZ87R57DV71M4,KAZ87R57DV71MS4,KAZ87R57DV71S4,KAZ87R57DV80K4,KAZ87R57DV80M4,KAZ87R57DV80MK4,KAZ87R57DV80N4,KAZ87R57DV80S4,KAZ87R57DV90L4,KAZ87R57DV90M4,KAZ87R57DV90S4,KAZ87R57DVE63L4,KAZ87R57DVE63M4,KAZ87R57DVE63MS4,KAZ87R57DVE63S4,KAZ87R57DVE71D4,KAZ87R57DVE71M4,KAZ87R57DVE71MS4,KAZ87R57DVE71S4,KAZ87R57DVE80K4,KAZ87R57DVE80M4,KAZ87R57DVE80MK4,KAZ87R57DVE80N4,KAZ87R57DVE80S4,KAZ87R57DVE90L4,KAZ87R57DVE90M4,KAZ87R57DVE90S4,KAZ87RF57-Y0.12KW,KAZ87RF57-Y0.12KW,KAZ87RF57-Y0.12KW,KAZ87RF57-Y0.18KW,KAZ87RF57-Y0.18KW,KAZ87RF57-Y0.18KW,KAZ87RF57-Y0.18KW,KAZ87RF57-Y0.25KW,KAZ87RF57-Y0.25KW,KAZ87RF57-Y0.25KW,KAZ87RF57-Y0.25KW,KAZ87RF57-Y0.37KW,KAZ87RF57-Y0.37KW,KAZ87RF57-Y0.37KW,KAZ87RF57-Y0.37KW,KAZ87RF57-Y0.55KW,KAZ87RF57-Y0.55KW,KAZ87RF57-Y0.55KW,KAZ87RF57-Y0.55KW,KAZ87RF57-Y0.75KW,KAZ87RF57-Y0.75KW,KAZ87RF57-Y0.75KW,KAZ87RF57-Y0.75KW,KAZ87RF57-Y1.1KW,KAZ87RF57-Y1.1KW,KAZ87RF57-Y1.1KW,KAZ87RF57-Y1.1KW,KAZ87RF57-Y1.5KW,KAZ87RF57-Y1.5KW,KAZ87RF57-Y1.5KW,KAZ87RF57-Y1.5KW,KAZ87RF57-Y63M4,KAZ87RF57-Y71M4,KAZ87RF57-Y80M4,KAZ87RF57-Y90M4,KAZ87RF57-YEJ63M4,KAZ87RF57-YEJ71M4,KAZ87RF57-YEJ80M4,KAZ87RF57-YEJ90S4,KAZ87RF57-YVP63M4,KAZ87RF57-YVP71M4,KAZ87RF57-YVP80M4,KAZ87RF57-YVP90S4,KAZ87RF57-YVPEJ63M4,KAZ87RF57-YVPEJ71M4,KAZ87RF57-YVPEJ80M4,KAZ87RF57-YVPEJ90S4。
K88R58減速電機生產廠家展示：看廠請聯系微信13827261050，獲取位置，需提前一天預約http://m.272323.com/product/list-kxiliejiansuji-cn.html
推薦型號：K88減速機
關鍵詞:GK型減速機配電機一體式_螺旋錐齒輪減速器_K系列減速機_雙出軸減速機_90度減速機_螺旋錐齒輪減速機_GK系列減速機_K系列減速器_雙出軸減速器_90度減速器
K系列齒輪減速馬達型號：K38減速機,K48減速機,K58減速機,K68減速機,K78減速機,K88減速機,K98減速機,K108減速機,K128減速機,K158減速機,K168減速機,K188減速機
K系列直角減速機可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機 0.12KW-200KW之間
如需工程師幫選型，請加微信13827261050，留言告知工程師參數要求
標簽: KHZ87R57 KVZ87R57 KAZ87R57
